Vacuum Blood collection Tube EDTA Tube
JINGZ tubes are glass or plastic tubes with a pre-defined vacuum for exact draw volumes. They are fitted with colour-coded JINGZ Safety Caps. The tubes, additive concentrations, volume of liquid additives, and their permitted tolerances, as well as the blood-to-additive ratio, are in accordance with the requirements and recommendations of the international standard ISO 6710 “Single-use containers for venous blood specimen collection“ and the Clinical and Laboratory Standards Institute’s Approved Standards (CLSI). Additive choice depends on the analytical test method. It is specified by the manufacturer of the test reagents and/or instrument on which the test is performed. Tube interiors are sterile.
JINGZ K2E K2EDTA Tubes and JINGZ K3E K3EDTA Tubes are used for testing whole blood in haematology. For parameter stability
information, i.e., whole blood count (CBC) and differential blood count (DIFF), follow the recommendations of the instrument
manufacturer. Refer to specific documents (i.e., guidelines, standards) for additional information. Blood smears should be prepared
within four hours of blood collection. EDTA Tubes may also be used for routine immunohaematology testing i.e. red cell grouping, Rh
typing and antibody screens, viral marker testing in screening laboratories and molecular diagnostics.
Specification
- Color Code: Purple, Lavender
- Volume: 2-10ml
- Size: 13*75mm, 13*100mm, 16*100mm
- Material: Glass, PET(Plastic)
- Shelf Time: 24 months for glass tube, 12 months for PET tube
- Centrifuge: No centrifugation performed
- Inversion Times: 8 -10 times
- Clotting Time: Blood will not freeze
-
| Material |
Size |
Volume |
Packing |
| Glass/PET |
13*75mm |
2-4ml |
100pcs/tray, 1200/1800pcs per carton
1million pcs a 20FT container
2million pcs a 40FT container
2.6milion pcs a 40HQ container
|
| Glass/PET |
13*100mm |
5-7ml |
| Glass/PET |
16*100mm |
8-10ml |
INSTRCUTION FOR USE
1. Check the tube first;
2. Insert the blood collection needle into the vein after the skin disinfection;
3. Put the puncture needle into rubber stopper and the blood will automatically flow into the tube;
4. After the blood is collected to the calibration capacity, first pull out the IV needle on body, then pull off the tube.
5. Gently reverse the tube 5-8 times after collection(except no additive plain tube).
HIGH ALTUTUDE
For collection at high altitude (1600 m/5250 ft or 3000 m/9850 ft) we recommend high altitude tubes. The vacuum in these tubes compensates for the lower outer pressure
PRECAUTIONS
1. Do not use tubes if foreign matter is present!
2. To ensure accurate test results, all JINGZ Blood Collection Tubes must be allowed to fill completely.
3. Handle all biological samples and blood collection “sharps“(lancets, needles, luer adapters, and blood collection sets) according to the policies and procedures of your facility.
STORAGE
1. The vacuum blood collection tubes should be stored in cool dry place at 4℃-25℃;
2. The vacuum blood collection tubes shall be vertical and prohibited to invert.
FAQ
1. Are you factory or trading company?
We are a factory established in 2005 under the name of Jiangxi Exquisite(JINGZ) Technology Co.Ltd in Jiangxi Xiaolan Industrial Park, with full production line and medical approval certificates. YBK Medical is the subsidary company of JINGZ to supply better sales and service to customers.
2. How can I contact your company?
Email us at jingz08@jxjzkj.cn, ivy.du@ybkmed.com or Whatsapp: 008615084880052. Welcome to visit our factory at Nanchang too.
3. Do you have an MOQ for blood tube and needle?
Yes, MOQ 12000pcs(10 cartons) for each size.
4. Is it ok to print our logo on label and packing carton?
Yes, we offer OEM/ODM service for our products. But OEM MOQ needs 200,000pcs.
